Prefabricated Steel Structure School Complex Solutions for Madagascar
As a leading steel building exporter, we specialize in delivering high-quality prefabricated steel structure school buildings tailored for emerging markets. Our Madagascar school project showcases170 PCS 2,700㎡ modular complex constructed with advanced light steel framing systems, achieving 98% factory prefabrication rate. Engineered for tropical climates, these seismic-resistant structures feature galvanized steel components with 50-year anti-corrosion warranty. Utilizing BIM-based modular design, we completed on-site installation within 45 days, demonstrating exceptional cost-efficiency with 30% savings compared to traditional construction.
| Component | Specification |
| Main Frame | Welded H-section (Q355B steel) |
| Purlin | C160×60×20×2.5mm (Q355B) |
| Wall Panel | 100mmPU sandwich panel (60KG/m³) |
| Roofl Panel | 100mmPU sandwich panel (60KG/m³) |
| Connection | 10.9S HV bolts (M24×65) |
| Coating | Hot-dip galvanizing 120μm + PVDF paint |
